Pump kit concentrated acids and alkalis
Features and benefits:
- for transferreing concentrated acids and alkalis like chromic acid, nitric acid, sulphric acid and sodium hypchlorate
- unique barrel pump design in PVDF throughout the world: a steel cored inner tube provides the ultimate in stability and extended service life of the mechanical seal - even at high temperatures
- sealed inner tube, the liquid being pumped cannot enter the inner tube
- optimum barrel emptying due to ideal impellor design
- to be stripped for cleaning with a minimum of effort
Pump Type:
- F 430 PVDF-40/33 in Polyvinylidenfluoride
Immersion length:
Motor Type:
- Commutator motor Type F 458, 460 Watt, IP 55
- with power supply cable, 5 m ong, and safety plug
- totally enclosed, fan cooled motor design with special corrosion-resistant painting, making this model particularly suitable for use in corrosive, vapour loaden atmospheres
New
Lever tap PVDF:
- Exact, sensitive measuring
- Higher flow rate
- Higher operational safety due to improved seal
Accessories supplied with the pump:
- Hose connection PVDF
- Chemical hose DN 19, 2 m long
- 2 hose clips
- Quick action tap PVDF, seal FKM
- Compression gland PP
Performance data
- obtained with water at 20 °C at the pump outlet
- Delivery rate max. 170 l/min
- Delivery head max. 9,5 m water column
- Viscosity max. 800 mPas (cP)
- Temperature max. 100 °C
